TGC16 3 Door Upright Display Freezer 1400L
$4,400.00 inc GST
Upright Display Freezer | 1400L | 3 Hinged Doors | Triple Glazed Glass | Auto Defrost
Display More. Sell More. Save More.
Key Features
- 1400L spacious capacity to showcase frozen seafood, ice cream, and packaged goods
- 12× adjustable shelves for flexible stocking and display options
- 3× triple glazed anit-fog glass hinge doors improve visibility and insulation
- Bright vertical LED lighting enhances product presentation and simplifies stocktaking
- Fan-forced dynamic cooling (-20°C to -17°C) with Carel digital temperature control
- Eco-friendly, energy efficient refrigeration (14.40kWh/24h) with auto defrost
- Stainless steel build with quiet, powerful performance in up to 43°C
Calculate Delivery Cost
- Description
- Size Guide
- Additional information
- Features
- Specifications
- Product Warranty
- Shipping & Returns
Description
Whether showcasing frozen products to customers or to see the contents of your kitchen freezer without opening the doors, our Wellquip TGC16 3 Door Upright Display Freezer 1400L offers a high performance refrigeration solution. Perfect for supermarkets, butcheries, seafood markets, retail and hospitality venues, it combines reliable cold storage and efficiency to showcase ice cream, frozen meals and packaged products in style
With a 1400L capacity and 12× sturdy adjustable shelves, this 3 Door Commercial Upright Display Freezer makes it easy to store and merchandise a range of frozen products like ice cream, seafood, meats and ready-to-go packaged meals. 3× triple glazed anit-fog glass display doors enhance thermal efficiency, while the bright interior LED lighting makes products easy to view and well-presented to customers.
The heavy-duty top-mounted Embraco compressor keeps refrigeration components away from floors and is ideal for high clearance ceilings. A dynamic refrigeration system with 2× powerful evaporator fans and auto defrost ensures rapid and even air circulation for everyday use in ambient temperatures up to 43°C. The Carel digital temperature controller with LED display maintains freshness between -20°C to -17°C, while the eco-friendly R290 refrigeration system delivers low energy consumption of just 14.4kWh/24h.
Constructed entirely from high-grade stainless steel for long-lasting durability in demanding commercial environments. 3× self-closing hinge doors in a sleek silver frame also feature 105° stay-open hinges to simplify stock control. Limit temperature loss with magnetic door seals and automatic door sensors that pause the fan cooling system when the doors are open.
5× castor wheels with front locks make it easy to move and position, while rounded internal corners and edges simplify cleaning and maintenance. Safeguard your inventory after hours with integrated door locks.
Practical, reliable and efficient, our heavy-duty Wellquip TGC16 3 Door Upright Display Freezer 1400L ensures steady performance in any commercial setting — so you can focus on delighting your customers.
Order now for a powerful but quiet refrigeration solution to elevate your front-of-house and back-of-house operations!

| size | chest(in.) | waist(in.) | hips(in.) |
|---|---|---|---|
| XS | 34-36 | 27-29 | 34.5-36.5 |
| S | 36-38 | 29-31 | 36.5-38.5 |
| M | 38-40 | 31-33 | 38.5-40.5 |
| L | 40-42 | 33-36 | 40.5-43.5 |
| XL | 42-45 | 36-40 | 43.5-47.5 |
| XXL | 45-48 | 40-44 | 47.5-51.5 |
Additional information
| Weight | 224 kg |
|---|---|
| Dimensions | 77.4 × 184 × 205 cm |
Features
- Design: Top-mounted heavy-duty Embraco compressor keeps refrigeration components away from floors and is ideal for high clearance ceilings. Compact footprint with maximum vertical display capacity for both merchandising and cold storage.
- Storage: 1400L storage capacity with 12× adjustable shelves for flexible storage and display.
- Display: Energy-efficient interior LED vertical lighting. 3× triple glazed anti-fog glass displays for insulation and reduced condensation.
- Cooling System: Fan-forced dynamic refrigeration with 2× powerful evaporator fans and auto defrost to maintain consistent cabinet temperatures between -20℃ to -17℃.
- Climate Rating: Climate class 4 (ST) rated for the Australian climate to operate in ambient temperatures of up to 43℃ and 55% RH humidity with a low noise design (<65 decibels). L1-rated -18°C to -15°C temperature class for frozen perishables.
- Efficiency: Eco-friendly R290 refrigerant and high density cyclopentane insulation results in low energy consumption (14.4kWh/24h). Magnetic door seals and automatic door sensors limit temperature loss by pausing the fan cooling system when the doors are open.
- Controls: Carel digital temperature controller with LED display for precise regulation.
- Construction: Durable stainless steel build throughout. Easy-to-clean cabinet with rounded edges and corners. 3× self-closing hinge doors in a sleek silver frame featuring 105° stay-open hinges for better stocktaking.
- Stability: 5× castor wheels for mobility with front locks for easy mobility and positioning.
- Security: Safeguard your inventory after hours with integrated door locks.
Specifications
| Technical | |
| Temperature Range | -20°C to -17°C |
| Air Circulation | Fan Forced
2× powerful evaporator fans Auto defrost |
| Refrigerant | R290 (160g) |
| Energy Consumption | 14.4kWH/24h |
| Climate Class | 4 (ST)
L1-rated -18°C to -15°C temperature class |
| Max. Ambient Temperature | +43°C |
| Humidity Testing Standard | 55% RH |
| Power Supply | Single phase 10A power plug at rear-top (2.6m length) |
| Voltage | 220-240V |
| Frequency | 50Hz |
| Rated Current | 7.0A |
| Power | 1400W |
| Build | |
| Volume | 1400L |
| Packaged Weight | 250kg |
| Unit Weight | 224kg |
| Door Design | 3 triple glazed anti-fog glass hinged doors
Silver door frame Self-closing and stay-open Automatic door sensors Lock and key set for each door |
| Shelving System | 12 Adjustable Shelves (5 tiers including base)
Left & Right Shelf Dimension: 535mm (W) x 525mm (D) Centre Shelf Dimension: 585mm (W) x 525mm (D) |
| Exterior Construction | Stainless steel |
| Interior Construction | Stainless steel |
| Air Intake Position | Top |
| Ventilation Position | Top
NB: Please ensure regular cleaning of the air dust filter |
| Clearance Required | 200mm Top |
| Dimensions | |
| External | 1800mm (W) x 740mm (D) x 1950mm (H) |
| Internal | 1700mm (W) x 540mm (D) x 1410mm (H) |
| Packaged | 1840mm (W) x 774mm (D) x 2050mm (H) |
